HbA1c Analyzer

Point-of-Care

  • Point-of-care HbA1c analyzer is a small, simple and easy-to-operate glycosylated hemoglobin analyzer, which can be used in many environments, including testing in hospital laboratories and outpatient clinics, and can provide accurate and stable analysis.
  • The test principle of HbA1c analyzer is that after the blood sample is reacted with the detection reagents (boronate affinity chromatography), the reagents precipitates the hemoglobin in the sample, and the boronic acid derivative binds to the cis-diols of glycated hemoglobin.
  • Using boronic acid derivatives as the tracer, the glycosylated hemoglobin analyzer uses dry chemical photoelectric colorimetry to detect the blue (glycated hemoglobin) and red (total hemoglobin) color intensity in the precipitate for quantitative analysis, thereby determining the glycated hemoglobin in the sample as a percentage of total hemoglobin.

Small and Smart

  • Fit in any POCT scenarios
  • Fully automatic
  • Least interference from HbA1c variants
  • No liquid path: no carryover & minimized maintenance
  • Auto calibration by tapping card

One Step Operation

  • Add sample - The test cartridge is placed in the instrument through the cartridge holder.
  • Insert into Analyzer - The blood is then mixed.
  • Start testing - Measured in 5 minutes to determine the HbA1c value.
Features
Features
  • Principle Linear range
    Boronate Affinity   Chromatography 3.5-15.0% (NGSP)
    Analytes Working Environment
    HbA1c, Glycated   Hemoglobin 10 ~ 30°C
    Sample Type Dimensions:
    Whole blood/diluted   blood 224mm(L)*   160mm(W)*236mm(H)
    Sample Volume Weight:
    5 μL ≤5 Kg
    CV Power Supply:
    ≤3% 100-240V, 50/60Hz
    Calibration Consumables
    RFID card swipe All-in-one   Cartridge(25 kits/box),

    RFID card,

    disposable pipette,

    HbA1c   Control(optional)
    Interval Configuration
    ≤5 min LAN port, USB, Serial Port, WiFi
